How to Install a Smart Lock (Keypad or Wi-Fi)

Frequently Asked Questions

Can I install a smart lock myself without a locksmith?

Yes. Almost all consumer smart locks are designed for DIY installation and work with standard door prep. If your door already has a deadbolt, you can swap it in 15-25 minutes with just a Phillips screwdriver.

Do smart locks work without Wi-Fi?

Yes. Bluetooth and keypad-only smart locks work fully offline — you unlock with a code or your phone near the door. Wi-Fi is only needed for remote control, guest codes from anywhere, and integration with Alexa, Google Home, or Apple Home.

Will a smart lock fit my door?

Most smart locks fit standard US doors with a 2-1/8 inch cross bore, 1 inch edge bore, and 1-3/8 to 1-3/4 inch door thickness. If you have a non-standard door or a mortise lock, verify compatibility before buying. Commercial or European doors often need a different model.

How long do smart lock batteries last?

Most smart locks run 6-12 months on 4 AA batteries. Wi-Fi models drain faster (3-6 months). The lock will warn you at 20% battery through the app. If batteries die, you can still use your physical key (on most models) or a 9V battery touched to the external contacts for a jump.

Are smart locks secure?

Yes, when installed correctly. Good smart locks use AES-128 encryption for Bluetooth and TLS for Wi-Fi. Choose a model with ANSI/BHMA Grade 2 or better. The biggest real-world risk is still a weak door frame — no lock stops a kick-in through a cracked jamb.

Can I keep using my regular keys?

Most smart locks include a keyed cylinder so you can still use a physical key. Some keyless models (like August smart locks that retrofit your existing deadbolt) keep your original key unchanged. Fully keyless models remove the keyway entirely for better security.

A smart lock turns your front door into your most convenient entry point — no more digging for keys, lending out spares, or wondering if you locked up. And it takes about 20 minutes and one screwdriver to install. This guide covers every step and helps you pick the right model for your door.

Do You Actually Need a Smart Lock?

Smart locks solve three real problems:

1. No more key juggling. Kids, dog walkers, cleaners, Airbnb guests — give anyone a temporary code instead of a physical key. Revoke it when they leave.
2. Remote lock/unlock. Forgot to lock up? Check the app. Package delivery while you’re at work? Unlock for the driver, then relock.
3. Access logs. See exactly when each family member came home, which code was used, and when the door was last locked.

They don’t solve: a weak door frame, old strike plate with short screws, or a cracked jamb. Burglars kick doors — they don’t pick locks. Before installing any lock, check that your strike plate has 3-inch screws driven into the stud behind the frame. That single upgrade matters more than the lock itself.

Choosing a Smart Lock (Under 5 Minutes)

There are four main types. Pick based on your priorities.

Keypad + Wi-Fi (Most Popular)

Best all-around pick. Unlock with a code, your phone, or a physical key. Wi-Fi lets you control it from anywhere.

• Schlage Encode Plus — Apple Home Key support, ANSI Grade 1, built-in Wi-Fi, $280-320. The most secure consumer smart lock on the market.
• Yale Assure Lock 2 — Clean design, reliable keypad, works with Alexa/Google/HomeKit, $190-260.
• Schlage Encode — Older Encode model without Home Key, still excellent, $220-260.

Retrofit (Keep Your Existing Keys)

Replaces only the interior thumbturn — your existing exterior lock and keys stay unchanged. Great for renters or anyone who wants to keep a specific key.

• August Wi-Fi Smart Lock (4th Gen) — Built-in Wi-Fi, compact, $200-250. Installs in 10 minutes without changing anything visible from outside.

Keyless (Maximum Security)

No keyway at all, which removes the most vulnerable part of any lock.

• Level Lock Plus — Invisible design, fits inside the door, Apple Home Key compatible, $330-380.

Keypad Only (No Wi-Fi Subscription Risk)

If you don’t trust cloud features or want to avoid a dependency on the manufacturer’s servers.

• Schlage Keypad Deadbolt (BE365) — Battery keypad, no app, no Wi-Fi, $90-120. Bulletproof choice if you just want codes.

Tools You Need

• Phillips screwdriver (#2)
• Tape measure (verify door specs before buying)
• Pencil (for marking)

That’s it. No drilling, no wiring, no permits. If this is your first install project, see our new homeowner toolkit guide for the rest of what’s worth having on hand.

Step 1: Verify Compatibility (2 Minutes)

Before you unbox anything, check three measurements:

1. Door thickness: Open the door and measure the edge. Standard is 1-3/8 to 1-3/4 inch. Most smart locks fit this range.
2. Cross bore diameter: The big hole in the face of the door. Standard is 2-1/8 inch.
3. Edge bore diameter: The smaller hole on the door’s edge where the latch goes. Standard is 1 inch.

If your door matches all three, any consumer smart lock will fit. Non-standard doors (European, commercial, mortise locks) need specific models — check the manufacturer’s compatibility page before buying.

Step 2: Remove the Old Deadbolt (3 Minutes)

1. Find the two screws on the interior thumbturn plate. Unscrew them.
2. Pull the interior thumbturn straight off.
3. From outside, pull the exterior cylinder off. It should slide right out.
4. On the door’s edge, unscrew the two screws holding the latch faceplate.
5. Pull the old latch out of the edge bore.

Save the old parts in a bag in case you ever want to reinstall.

Step 3: Install the New Latch (2 Minutes)

1. Look at the latch. One side of the beveled edge faces the direction the door closes — put that side in the correct orientation.
2. Slide the new latch into the edge bore.
3. Screw the faceplate into the edge of the door with the two provided screws.

If the latch doesn’t sit flush, the new faceplate may be a different size than the old one. Most smart locks include a chisel-free faceplate (just screws on). If yours requires the faceplate to sit inside a mortise, you may need to trim the existing mortise slightly with a chisel.

Step 4: Mount the Exterior Half (5 Minutes)

1. From outside, push the keypad or cylinder through the cross bore. The tailpiece (the flat metal bar at the back) must engage the slot in the latch.
2. Hold the exterior half in place with one hand while you go inside.
3. Ensure the tailpiece is fully seated — it should not wiggle independently of the latch.

If the tailpiece doesn’t engage, pull it back out and check that it’s in the correct orientation (it usually has a specific “up” direction indicated by a notch).

Step 5: Attach the Interior Half (5 Minutes)

1. Most smart locks have a cable that runs from the keypad to the interior body. Thread it through the hole in the mounting plate.
2. Hold the interior body against the mounting plate.
3. Screw the two long mounting screws through the interior body, through the door, and into the exterior half.
4. Hand-tighten only. Overtightening warps the lock body and causes the latch to bind. Tighten until snug, then stop.
5. Connect the ribbon cable from the keypad to the interior body (if applicable).

Step 6: Batteries and Manual Test (2 Minutes)

1. Pop the battery cover off the interior body.
2. Insert the batteries (usually 4 AA — use lithium AA batteries for cold-weather reliability and longer life).
3. Replace the battery cover.
4. Turn the interior thumbturn back and forth. The latch should extend and retract smoothly.
5. Close the door and test that the latch engages the strike plate without resistance.

If the latch binds, loosen the two mounting screws slightly. If it still binds, the strike plate may need to be slightly adjusted (most door frames are forgiving).

Step 7: Pair With Your Phone (3-5 Minutes)

Install the manufacturer’s app. Most smart locks use their own app:

• Schlage: Schlage Home
• Yale: Yale Access
• August: August (same app as Yale)
• Level: Level Home
• Kwikset: Kwikset App

1. Create an account (skip marketing opt-ins).
2. Put the lock in pairing mode (usually hold a button on the interior body until it flashes).
3. Follow the app’s pairing flow. It will take 30-60 seconds.
4. If the lock has Wi-Fi, connect it to your home Wi-Fi (2.4 GHz only — smart locks don’t support 5 GHz).

Step 8: Calibrate and Add Users (5 Minutes)

Most smart locks run a calibration routine that teaches the motor the locked and unlocked positions.

1. In the app, find “Calibrate” or it may start automatically.
2. Follow the prompts — usually lock and unlock manually when asked.
3. Add family members with their own app access or PIN codes.
4. Set up guest codes for anyone else who needs access. Time-limited codes are the killer feature.

Enable auto-lock if you want the door to lock itself after 30-60 seconds. This is the single feature that will pay back the installation time.

Troubleshooting

Latch binds when door is closed. The mounting screws are too tight or the strike plate is misaligned. Loosen the screws slightly. If still binding, the strike plate may need shimming.

Lock won’t pair with the app. Toggle Bluetooth off and on. Stand within 3 feet of the lock. Confirm your phone’s OS is up to date.

Keypad doesn’t respond. Batteries are low or inserted backward. Replace with fresh batteries.

Wi-Fi drops constantly. Your router is too far. Add a mesh Wi-Fi node near the front door, or move the router closer.

Door won’t latch without lifting. The hinges have sagged. Tighten the top hinge screws (the door sags when hinge screws loosen over time). If still sagging, swap one hinge screw for a 3-inch screw that reaches the stud.

What Not to Do

• Don’t overtighten the mounting screws. This is the #1 installation mistake. It warps the lock body and causes the latch to bind against the strike plate.
• Don’t install on a poorly-fitted door. A smart lock won’t fix a door that already doesn’t close properly. Fix the fit first.
• Don’t skip the strike plate upgrade. A $5 pack of 3-inch screws in the strike plate makes any lock dramatically more kick-resistant.
• Don’t use rechargeable batteries. Most smart locks are not designed for the lower voltage of NiMH rechargeables. Use lithium or alkaline.

Ongoing Maintenance

• Every 6 months: Check battery level in the app. Replace batteries before they hit 10%.
• Yearly: Lubricate the latch with a dry graphite or silicone lubricant (not WD-40 — it attracts dirt).
• If keys exist: Keep a physical backup key in a lockbox or with a trusted neighbor, not in your car.
